High Efficiency Hydraulic Pump Caproni Gear Pump CBN-F312CLPR 3 Mode
You are here: Home » Products » Hydraulic Motor » Ungrouped » High Efficiency Hydraulic Pump Caproni Gear Pump CBN-F312CLPR 3 Mode

loading

High Efficiency Hydraulic Pump Caproni Gear Pump CBN-F312CLPR 3 Mode

Pictures are for display only, please contact us to choose the right product for you.
Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

  • CBN-F312CLPR

  • Xeriwell or Others

Product Name: Hydraulic Gear Pump Model No.: CBN-F312CLPR
Displacement: 12 Cc Pressure: 20 Mpa
Rotation: Right Shaft: Straight Shaft, Parallel Key
Mode: 3 Flange: Square
Port: Screw Connect Rated Speed: 2000 Rpm
Highlight:

industrial hydraulic pump

,

high pressure gear pump


Caproni pump CBN-F312CLPR

We design & make huge range of gear pumps with many options . Also customize according to customers' samples or drawings.

Group 1, group 2 and group 3 gear pumps, single & multiple SAE A and SAE B, single and multiple.
Used on tractor of , , Massey Ferguson, , David Brown, Deutz, Fendt, Fiat, Ford, Lamborgini, Same, Cat, Komatsu, , etc.
Nice quality PK Bulgaria & USA makes, we make nice quality in shor time, you can buy same quality from us with price only 1/3 - 1/5.
Excellent performance compatible with Parker, Rexroth, Caproni, Cassapa, replace OEM parts you may find on original machines

Specifications:

Type Displacement Max.pressure Max.speed Min.speed
P1 P2 P3

cm3/rev bar bar bar r/min r/min
CBT 3 270 285 300 4000 800
CBT 4 270 285 300 4000 600
CBT 6 270 285 300 4000 600
CBT 8 270 285 300 3500 500
CBT 10 270 285 300 3000 500
CBT 12 270 285 300 3000 500
CBT 14 250 265 280 4000 500
CBT 16 250 265 280 4000 500
CBT 18 250 265 280 3600 400
CBT 20 220 235 250 3200 400
CBT 22 220 235 250 3000 400
CBT 25 200 215 230 3000 400
CBT 28 180 190 200 2500 400
CBT 30 160 170 180 2500 400

Applications:

  1. agriculture,

  2. mining,

  3. marine,

  4. forestry,

  5. construction plant,

  6. textile,

  7. food processing.

  9. Claas

  11. Parker

  12. Rexroth

  13. Caproni

Xeriwell We are specialized in producing hydraulic orbital motors, hydraulic steering Unit and other hydraulic products.
The products can be widely used for different kinds of Construction Equipments, Heavy equipments, Agricutural machines and Industrial machines etc.Machines like , Komatsu, Hitachi, , , , , Massey ferguson, Fiat, MTZ, etc.

--982-982Hydraulic
