TB0130AS110AAAB
Xeriwell or Others
Item: | Torqmotor | OEM #: | TB0130AS110AAAB |
---|---|---|---|
Manufacturer: | Xeriwell | Displacement: | 130 Ml/r |
Mounting Flange: | 2-hole | Shaft Type: | 6-B |
Highlight: | tb0130 parker torqmotor,tb series parker torqmotor,parker torqmotor hydraulic motor |
Quick review:
Compatible for TB0130AS110AAAB Parker low speed, high torque hydraulic motor. 7.2 cu. in. / rev displacement. Maximum pressure 1840 PSI continuous, maximum pressure 2425 PSI intermittent. Torque 1790 in-lb. continuous, torque 2372 in-lb. intermittent. Maximum speed 475 RPM continuous. Flow rate 15.8 GPM. SAE 6B spline shaft. 7/8-14 SAE ports. 2 Bolt SAE mounting flange.1 year warranty.
Small Frame Low Speed, High Torque Motor
Manufacturer: Xeriwell
Details specifications
Series: | TB |
Shaft: | 1" 6B Spline |
Rotation: | Standard |
Displacement (cm3/rev): | 0130 |
Mounting: | SAE "A" 2 Bolt |
Ports: | 7/8-14 SAE |
Geometric Displacement: | 130 cm3/rev (8.0 in3/rev) |
Maximum Speed: | 430 rev/min |
Maximum Oil Flow (continuous / intermittent): | 45 lpm (12 gpm) / 57 lpm (15 gpm) |
Max. Differential Pressure (continuous / intermittent): | 125 bar (1800 PSID) / 165 bar (2400 PSID) |
Maximum Supply Pressure: | 190 bar (2750 PSID) |
Maximum Torque - Continuous / Intermittent: | 220 Nm (1951 lb in) / 297 Nm (2632 lb in) |
Maximum Performance: | 13.4 KW (18.0 HP) |
Minimum Starting Torque - Continuous / Intermittent: | 167 Nm (1482 lb in) / 229 Nm (2024 lb in) |
Maximum Side Load at Key: | 4900 N (1100 lb)Shaft Code: 11 |
More Parker type Torque motors:
TB, TC, TJ, TE, TF, TG, TK
