| Product: | Low Speed High Torque Motor | Material: | Cast Iron |
| Displacement: | 200 Ml/r | Speed: | 229-289 Rpm |
| Torque: | 382-520 Nm | Output: | 9-15.7 Kw |
| Pressure Drop: | 14 - 19 MPa | Flange: | SAE A Mount |
| Shaft: | 1 Inch 6B Spline Shaft | Rotation: | CCW |
| Highlight: | High Torque series Motor tb0195,G1/2 series Motor tb0195,SAE A flange series Motor tb0195 |
Parker TB series motor TB0195,SAE A flange, G1/2 BSPP ports, spline 6B shaft - Low Speed High Torque Motor
Quick review:
Model number: BME2-200-HD-S-R
Displacement:200 ml/r
Speed, 229-289 rpm
Torque, 382-520 Nm
Output, 9-15.7 Kw
Pressure Drop, 14 - 29 MPa
Flange, square mount
Shaft, 25.4mm key shaft with hole
Rotation, CCW
Features, suit Parker TB0195AW110AAAA
Here is it's technical details:
| Type | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 |
| 65 | 80 | 100 | 125 | 160 | 200 | 230 | 250 | 295 | 315 | 375 |
| Geometric displacement (cm3 /rev.) | 66.8 | 81.3 | 101.6 | 127 | 157.2 | 193.6 | 226 | 257 | 287.8 | 314.5 | 370 |
| Max. speed (rpm) | cont. | 667 | 543 | 439 | 350 | 283 | 229 | 247 | 216 | 196 | 178 | 152 |
| int. | 842 | 689 | 553 | 441 | 355 | 289 | 328 | 287 | 254 | 235 | 199 |
| Max. torque (N•m) | cont. | 126 | 157 | 191 | 245 | 307 | 382 | 378 | 381 | 393 | 448 | 439 |
| int. | 176 | 215 | 268 | 335 | 422 | 520 | 528 | 543 | 547 | 587 | 613 |
| Max. output (kW) | cont. | 8.3 | 8.8 | 7.9 | 8.9 | 8.9 | 9 | 9.9 | 9.3 | 8.7 | 8 | 7.6 |
| int. | 13.9 | 14.4 | 13.5 | 14.1 | 15.6 | 15.7 | 17.9 | 16.5 | 15.6 | 14.3 | 14 |
| Max. pressure drop (MPa) | cont. | 14 | 14 | 14 | 14 | 14 | 14 | 12 | 11 | 10 | 10 | 9 |
| int. | 19 | 19 | 19 | 19 | 19 | 19 | 165 | 15.5 | 14.5 | 13.5 | 12.5 |
| peak | 20 | 20 | 20 | 20 | 20 | 20 | 18 | 18 | 17 | 16 | 16 |
| Max. flow (L/min) | cont. | 45 | 45 | 45 | 45 | 45 | 45 | 57 | 57 | 57 | 57 | 57 |
| int. | 57 | 57 | 57 | 57 | 57 | 57 | 75 | 75 | 75 | 75 | 75 |
Orbital Motor Key Advantages
1. High Output Torque for Heavy-Duty Operations
Orbital motors deliver substantial constant torque at steady rotational speeds over prolonged operation, ensuring consistent, stable power output. This performance characteristic makes them perfectly suited for industrial scenarios demanding dependable precision and uninterrupted power delivery.
2. Explosion-Proof Variant Ensures Superior Operational Safety
Our fully enclosed explosion-proof orbital motors operate securely in harsh surroundings including dusty, damp, and even subaqueous conditions, as well as hazardous flammable atmospheres. They demonstrate far greater operational reliability compared to conventional flameproof electric motors.
3. Robust Reliability & Extended Service Lifespan
With routine proper maintenance, orbital hydraulic motors feature outstanding durability and a long service life. For round-the-clock continuous-duty equipment, their long lifespan effectively cuts downtime and reduces maintenance workloads, significantly boosting overall operational productivity.
4. Versatile Control with Remote Operation Support
These motors support seamless regulation of rotational speed and rotation direction, delivering precise motion and positioning control ideal for automated robotics and CNC equipment. Stable power output further elevates system accuracy. Additionally, full remote control capability allows operators to manage machinery from a safe distance, which is invaluable for hard-to-reach or high-risk working zones, maximizing operational safety and control flexibility.
5. Excellent Energy Efficiency
Orbital hydraulic motors boast remarkable energy conversion efficiency, converting the vast majority of input hydraulic power into usable mechanical power. Their sustained high efficiency under continuous running conditions curtails energy loss and lowers long-term operational expenses.
Exclusive Strengths of Xeriwell Orbital Motors
Beyond the universal merits listed above, hydraulic orbital motors manufactured by Xeriwell possess distinctive competitive edges. Our compact-sized units maintain exceptional durability even under extreme working environments.
We supply complete hydraulic solutions for travel drive, steering, power transmission, and lifting systems. Feel free to reach out to us for customized orbital motor solutions tailored to your unique equipment requirements.
