PGP
Xeriwell or Others
| PGP020 Frame Size | 5 | 7 | 10 | 12 | 15 | 17 | 20 |
| Displacement – cm3/rev (in3/rev) | 16.1 (0.99) | 24.2 (1.48) | 32.3 (1.97) | 40.4 (2.46) | 48.4 (2.96) | 56.5 (3.45) | 64.6 (3.94) |
| Max continuous pressure – bar (psi) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 172 (2,500) | 172 (2,500) |
| Max Speed – RPM | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Approximate Weight – Lbs. [kg] | 26 [12] | 27 [12.5] | 28 [13] | 29 [13] | 31 [14] | 33 [15] | 34 [15.5] |
| PGP031 Frame Size | 5 | 7 | 10 | 12 | 15 | 17 | 20 |
| Displacement – cm3/rev (in3/rev) | 16.1 (0.99) | 24.2 (1.48) | 32.3 (1.97) | 40.4 (2.46) | 48.4 (2.96) | 56.5 (3.45) | 64.6 (3.94) |
| Max continuous pressure – bar (psi) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 172 (2,500) | 172 (2,500) |
| Max Speed – RPM | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Approximate Weight – Lbs. [kg] | 30 [13.5] | 31 [14] | 33 [15] | 34 [15.5] | 35 [16] | 36 [16.5] | 37 [17] |
| PGP051 Frame Size | 5 | 7 | 10 | 12 | 15 | 17 | 20 | 22 | 25 |
| Displacement – cm3/rev (in3/rev) | 20.9 (1.28) | 31.3 (1.91) | 41.8 (2.55) | 52.2 (3.19) | 62.7 (3.83) | 73.1 (4.46) | 83.6 (5.10) | 94.0 (5.74) | 104.5 (6.38) |
| Max continuous pressure – bar (psi) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 172 (2,500) | 172 (2,500) | 172 (2,500) |
| Max Speed – RPM | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Approximate Weight – Lbs. [kg] | 34 [15.5] | 35.5 [16] | 37 [17] | 38.5 [17.5] | 40 [18] | 41.5 [19] | 43 [19.5] | 48.5 [22] | 50 [22.5] |
| PGP076 Frame Size | 7 | 10 | 12 | 15 | 17 | 20 | 22 | 25 | 27 | 30 |
| Displacement – cm3/rev (in3/rev) | 50.4 (3.08) | 67.2 (4.10) | 84.0 (5.13) | 100.8 (6.15) | 117.6 (7.18) | 134.4 (8.20) | 151.2 (9.23) | 168.0 (10.25) | 184.8 (11.28) | 201.6 (12.30) |
| Max continuous pressure – bar (psi) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 207 (3,000) | 172 (2,500) | 172 (2,500) | 172 (2,500) | 138 (2,000) | 138 (2,000) |
| Max Speed – RPM | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 | 2400 |
| Approximate Weight – Lbs. [kg] | 70 [32] | 72 [33] | 75 [34] | 77 [35] | 80 [36] | 82 [37] | 85 [39] | 87 [40] | 90 [41] | 92 [42] |
