| Quantity: | |
|---|---|
BMV800cc
Xeriwell or Others
| Features: | High Pressure Oil Seal | Product Name: | BMV800 / OMV800 Orbital Motor |
|---|---|---|---|
| Brand Name: | Xeriwell | Model Number: | Xeriwell BMV800cc |
| Displacement: | 315cc--1000cc | Application: | Mining Equipment |
| Highlight: | lightweight hydraulic motor,bmp hydraulic motor | ||
OMV800 / BMV800 Hydraulic Motor Shaft 50mm For Mining Equipment
1. Characteristic Features
• Constant operating torque over a wide speed range
• Smooth running over the entire speed range
• High starting torque
• High pressure oil seals
2. Specification
| Type | BMV 315 | BMV 400 | BMV 500 | BMV 630 | BMV 800 | BMV 1000 | |
| Geometric displacement (cm3 /rev.) | 333 | 419 | 518 | 666 | 801 | 990 | |
| Max. speed (rpm) | cont. | 510 | 500 | 400 | 320 | 250 | 200 |
| int. | 630 | 600 | 480 | 380 | 300 | 240 | |
| Max. torque (N·m) | cont. | 920 | 1180 | 1460 | 1660 | 1880 | 2015 |
| int. | 1110 | 1410 | 1760 | 1940 | 2110 | 2280 | |
| peak | 1290 | 1640 | 2050 | 2210 | 2470 | 2400 | |
| Max. output (kW) | cont. | 38 | 47 | 47 | 40 | 33 | 28.6 |
| int. | 46 | 56 | 56 | 56 | 44 | 40 | |
| Max. pressure drop (MPa) | cont. | 20 | 20 | 20 | 18 | 16 | 14 |
| int. | 24 | 24 | 24 | 21 | 18 | 16 | |
| peak | 28 | 28 | 28 | 24 | 21 | 18 | |
| Max. flow (L/min) | cont. | 160 | 200 | 200 | 200 | 200 | 200 |
| int. | 200 | 240 | 240 | 240 | 240 | 240 | |
3. Application
• Cone Splitter
• Excavator Splitter
• Drilling Machine
• Mining Equipment
• Geological exploration
High quality products,Offer the lowest price,Protect customers profit and Offer the best after service are our principle.
Our processing equipment from Germany,oil seal is high pressure oil seal,precision parts processing and strict quality control.
We are looking for good long cooperation in the hydraulic field,very hope we can become good long partner.
Hope I can get your chance to have a good long cooperation.
