BMH
Xeriwell or Others
OMH BMH 200/250/315/400/500 orbital hydraulic motor technical data:
| BMH Technical Data | ||||||
| Type | BMH 200 | BMH 250 | BMH 315 | BMH 400 | BMH 500 | |
| Geometric displacement (cm³/rev.) | 203.2 | 255.9 | 316.1 | 406.4 | 489.2 | |
| Max. speed (rpm) | cont. | 366 | 290 | 236 | 183 | 155 |
| int. | 439 | 348 | 282 | 220 | 184 | |
| Max. torque (N•m) | cont. | 510 | 621 | 740 | 850 | 830 |
| int. | 579 | 702 | 827 | 990 | 1040 | |
| peak | 651 | 790 | 980 | 1092 | 1170 | |
| Max. output (kW) | cont. | 16 | 16 | 14 | 12.5 | 11 |
| int. | 18.5 | 18.5 | 15.5 | 15 | 14 | |
| Max. pressure drop (MPa) | cont. | 17.5 | 17.5 | 17.5 | 15.5 | 12.5 |
| int. | 20 | 20 | 20 | 19 | 16 | |
| peak | 22.5 | 22.5 | 22.5 | 21 | 18 | |
| Max. flow (L/min) | cont. | 75 | 75 | 75 | 75 | 75 |
| int. | 90 | 90 | 90 | 90 | 90 | |
| Weight (kg) | 10.5 | 11 | 11.5 | 12.3 | 13 | |
| Type | Max.inlet pressure | Max.return pressure with drain line | ||||
| BMH200-500 (bar) | cont. | 20 | 17.5 | |||
| int. | 22.5 | 20 | ||||
| peak | 25 | 22.5 | ||||
| * Continuous pressure:Max. value of operating motor continuously. * Intermittent pressure:Max. value of operating motor in 6 seconds per minute. * Peak pressure:Max. value of operating motor in 0.6 second per minute. * Technical data BMH with 35mm cylindnical,1⊃1;/₄ in splined and 35mm tapered shaft. | ||||||
