| 性能参数 Parameters | 型号Type | |||||||||||
| BPBS1，BPBS2 | BPBS1 | |||||||||||
| 排量 Displacement | mL/r | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 | 280 | 315 | 400 |
| 公称流量① Rated Flow① | L/min | 5 | 6 | 8 | 10 | 12.5 | 16 | 20 | 25 | 28 | 31.5 | 40 |
| 最大入口压力 Max.Input Pressure | MPa | 17.5 | ||||||||||
| T口最大连续背压 Max.Cont.Pressure in Line T | MPa | 2.5 | ||||||||||
| 安全阀压力设定值 Relief Valve Pressure Settings | MPa | 6,8,10,12,14,16,17.5 | ||||||||||
| 过载阀压力设定值 Shock Valves Pressure Settings | MPa | 12,10,14,16,18,20,23.5 | ||||||||||
| 动力转向扭矩 Power Steering Torque | N.m | 1.6 – 2.4 | ||||||||||
| 最大输入扭矩 Max.Manual Steering Torque | N.m | 130 | ||||||||||
| 长度 L Dimension | mm | 130 | 132 | 133 | 136 | 139 | 144 | 149 | 155 | 160 | 165 | 175 |
| 重量 Weight | kg | 5.8 | 5.9 | 6 | 6.1 | 6.2 | 6.4 | 6.5 | 6.7 | 7 | 7.2 | 7.4 |
| 注①:公称流量为转速100rpm时转向器所需流量。 Note①:Rated flow for steering wheel that rotates at 100rpm. | ||||||||||||
| 代 号 CODE | 油口P,T,L,R螺纹 | 转柱安装螺纹C | 安装螺纹V | |
| Ports P,T,L,R | Column Mounting C | Valve Mounting V | ||
| Y | M20×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y1 | M22×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y2 | M18×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y3 | G1/2–14 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y4 | 3/4–16UNF O–ring Deep14mm | 3/8–16UNC Deep17mm | 3/8–24UNF Deep16mm | |
| Y5 | M20×1.5 O–ring Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y6 | M18×1.5 O–ring Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm |
| 性能参数 Parameters | 型号Type | |||||||||||
| BPBS1，BPBS2 | BPBS1 | |||||||||||
| 排量 Displacement | mL/r | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 | 280 | 315 | 400 |
| 公称流量① Rated Flow① | L/min | 5 | 6 | 8 | 10 | 12.5 | 16 | 20 | 25 | 28 | 31.5 | 40 |
| 最大入口压力 Max.Input Pressure | MPa | 17.5 | ||||||||||
| T口最大连续背压 Max.Cont.Pressure in Line T | MPa | 2.5 | ||||||||||
| 安全阀压力设定值 Relief Valve Pressure Settings | MPa | 6,8,10,12,14,16,17.5 | ||||||||||
| 过载阀压力设定值 Shock Valves Pressure Settings | MPa | 12,10,14,16,18,20,23.5 | ||||||||||
| 动力转向扭矩 Power Steering Torque | N.m | 1.6 – 2.4 | ||||||||||
| 最大输入扭矩 Max.Manual Steering Torque | N.m | 130 | ||||||||||
| 长度 L Dimension | mm | 130 | 132 | 133 | 136 | 139 | 144 | 149 | 155 | 160 | 165 | 175 |
| 重量 Weight | kg | 5.8 | 5.9 | 6 | 6.1 | 6.2 | 6.4 | 6.5 | 6.7 | 7 | 7.2 | 7.4 |
| 注①:公称流量为转速100rpm时转向器所需流量。 Note①:Rated flow for steering wheel that rotates at 100rpm. | ||||||||||||
| 代 号 CODE | 油口P,T,L,R螺纹 | 转柱安装螺纹C | 安装螺纹V | |
| Ports P,T,L,R | Column Mounting C | Valve Mounting V | ||
| Y | M20×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y1 | M22×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y2 | M18×1.5 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y3 | G1/2–14 Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y4 | 3/4–16UNF O–ring Deep14mm | 3/8–16UNC Deep17mm | 3/8–24UNF Deep16mm | |
| Y5 | M20×1.5 O–ring Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm | |
| Y6 | M18×1.5 O–ring Deep14mm | M10×1.5 Deep17mm | M12 Deep16mm |
