Hydraulic Gear Pump
Xeriwell or Others
| Product Name: | High Efficiency Hydraulic Pump | Pressure Level: | 16 MPa |
|---|---|---|---|
| Displacement (ml/r): | 04,06,08,10,12,14,16,20,25 | Applications: | , Fiat Tractors Fiat / Fiatagri 80-90 |
| Direction Of Rotation: | Left , Right | Gear Modulus: | 3 |
| Highlight: | industrial hydraulic pump,high pressure gear pump | ||
/ FIAT / FORD / Tractor Gear Pump A42XP4MS
Our CBN series gear pumps are widely used to replace various imported brands such as Eaton, Charing, , etc.
Technical parameters
Main Specifications:
| F1 | F2 | ||||
| Displacement (ml/r) | Inlet Port | Out Port | Displacement (ml/r) | Inlet Port | Out Port |
| 06 | 47.6x22.2 φ23 | 47.6x22.2 φ20 | 06 | 52.4x 26.2 φ23 | 7.6x22.2 φ20 |
| 08 | 08 | ||||
| 10 | 10 | ||||
| 12 | 12 | ||||
| 14 | 14 | ||||
| 16 | 16 | ||||
| 18 | 52.4x26.2 φ26 | 18 | 52.4x26.2 φ26 | ||
| 20 | 20 | ||||
| 23 | 23 | ||||
| 25 | 25 | ||||
| 27 | 27 | ||||
| 30 | 30 | ||||
| 32 | 32 | ||||
| 36 | 36 | ||||
| 40 | 40 | ||||
| S | FS | ||||
| Displacement (ml/r) | Inlet Port | Out Port | Displacement (ml/r) | Inlet Port | Out Port |
| 06 | M22x1.5-6H | M18x1.5-6H | 06 | 52.4x26.2 φ26 | M22x 1.5-6H |
| 08 | 08 | ||||
| 10 | 10 | ||||
| 12 | 12 | ||||
| 14 | 14 | ||||
| 16 | 16 | ||||
| 18 | M33x2-6H | M27x2-6H | 18 | M33x 2-6H | |
Xeriwell Gear Pump Features:
1. Low noise and long service life
2. Application of high strength aluminum alloy materials, light weight, low installation labor intensity
3. Input shaft types: key,rectangular spline,involute spline and woodruff
4. Connections types for the inlet and outlet ports: thread or flange etc.
5. Axial gap automatic compensation mechanism keeps high volumetric efficiency
Applications:
This series pumps are widely used in tractors, reapears, construction machinery, forklift, sanitation trucks and other hydraulic systems, etc.
Xeriwell Is an enterprise specializing in the production of BM series cycloid hydraulic motor, BZZ full hydraulic steering gear, hydraulic gear pump, FK combination valve block and other hydraulic components. The products are widely used in engineering machinery, mining machinery, metallurgical machinery, petroleum machinery, agricultural machinery, injection molding machinery, fishery machinery military engineering and other fields.
Xeriwell Hydraulic gear pump for any hydraulic system, our company uses high-end machine tools, excellence, the most humane service, manufacture and service the world, with good products and services to serve the world, welcome advice.
| 型 号 Model | A (mm) | B (mm) | D(mm) | |
| 进油口 Inlet | 出油口 Outlet | |||
| CBN–E(F)304 | 43.3 | 98.5 | Φ14 （M20×1.5，ZG1/2”） | Φ10 （M18×1.5，ZG3/8”） |
| CBN–E(F)306 | 45 | 102 | ||
| CBN–E(F)308 | 46.5 | 105 | ||
| CBN–E(F)310 | 48 | 108 | Φ18 （M20×1.5，ZG3/4”） | Φ14 （M18×1.5，ZG1/2”） |
| CBN–E(F)312 | 49.5 | 111 | ||
| CBN–E(F)314 | 51 | 114 | ||
| CBN–E(F)316 | 52.5 | 117 | ||
| CBN–E(F)320 | 56 | 124 | ||
| CBN–E(F)325 | 60 | 130 | ||
| ■性能参数 Specification | |||||||
| 型 号 Model | 公称排量(ml/r) Nominal Displacement | 压力(MPa) Pressure | 转速(r/min) Speed | 容积效率(≥%) Volumetric efficiency | 输入功率(kw) Input Powel | ||
| 额定Rated | 最高Max | 额定Rated | 最高Max | ||||
| CBN-E(F)304 | 4 | E16 F20 | E20 F25 | 2000 | 3000 | ≥92 | 3 |
| CBN-E(F)306 | 6 | 4.6 | |||||
| CBN-E(F)308 | 8 | 6.1 | |||||
| CBN-E(F)310 | 10 | 7.7 | |||||
| CBN-E(F)312 | 12 | 9 | |||||
| CBN-E(F)314 | 14 | 10.3 | |||||
| CBN-E(F)316 | 16 | 12.8 | |||||
| CBN-E(F)320 | 20 | 16.1 | |||||
| CBN-E(F)325 | 25 | 17.4 | |||||
