BMP/OMP , BMR/OMR
Xeriwell or Others
| Features: | High Pressure Oil Seal | Product Name: | Hydraulic Drive Motor BMP , BMR |
|---|---|---|---|
| Brand Name: | Xeriwell | Model Number: | BMP250,BMR315 |
| Displacement: | 50cc - 500cc | Application: | Mining, Forestry, Orchard Equipment |
| Highlight: | heavy duty hydraulic motor,hydraulic lift motor | ||
Hydraulic Drive Motor BMP , BMR For Mining , Forestry , Orchard Hydraulic Motor
1. Characteristic Features
♦ Advanced manufacturing devices for the Gerolor gear set, which use low pressure of start-up, provide smooth reliable operation and high efficiency.
♦ Shaft seal can bear high pressure of back and the motor can be used in parallel or in series.
♦ Special design in the driver-linker and prolong operating life.
♦ Special design for distribution system can meet the requirement of low noise of unit.
♦ Compact volume and easy installation.
♦ The output shaft, with the deep groove ball bearing, can bear certain axial force and radial force.
♦ With two inner check valves, no drain connection.
2. Specification
| MOTOR CROSS REFERENCE TABLE | ||||||||
| Xeriwell HYDRAULIC | M+S HYDRAULIC | EATON CHAR LYNN | ROSS TRW | WHITE CROSS | PARKER | SAM BREVINI | BOSCH RECROTH | |
| BMM | MM MLHK | J SERIES | OMM | BGM | MGX | |||
| BMP | MP HP | H SERIES | OMP DH | MF MG | WP RS | TC TE TB | BG | MGP GXP |
| BMR | MR HR MLHRW,RW | S,T SERIES W SERIES | OMR DS OMEW | MB | WR RE | TF | BR | MGR GMR |
| BMH | MH MLHH HW HWF | OMH | ME | RE | TG | |||
| BMS | MS MSY MLHS | 2000 SERIES | OMS | ME | RE | TG | HPR | MGS GMS |
| BMT | MT MLHT MTM | 6000 SERIES | OMT TMT | MJ | HT | MGT,GMT | ||
| BMV | MV MLHV | 10000 SERIES | OMV | MGV G | ||||
| Type | BMP 36 | BMP 50 | BMP 80 | BMP 100 | BMP 125 | BMP 160 | BMP 200 | BMP 250 | BMP 315 | BMP 400 | BMP 500 | |
| Geometric displacement (cm3 /rev.) | 36 | 51.7 | 77.7 | 96.2 | 120.2 | 157.2 | 194.5 | 240.3 | 314.5 | 389.5 | 486.5 | |
| Max. speed (rpm) | cont. | 1500 | 1150 | 770 | 615 | 490 | 383 | 310 | 250 | 192 | 155 | 120 |
| int. | 1650 | 1450 | 960 | 770 | 615 | 475 | 385 | 310 | 240 | 190 | 150 | |
| Max. torque (N·m) | cont. | 55 | 100 | 146 | 182 | 236 | 302 | 360 | 380 | 375 | 360 | 385 |
| int. | 76 | 128 | 186 | 227 | 290 | 370 | 440 | 460 | 555 | 525 | 560 | |
| peak | 96 | 148 | 218 | 264 | 360 | 434 | 540 | 550 | 650 | 680 | 680 | |
| Max. output (kW) | cont. | 8 | 10 | 10 | 11 | 10 | 10 | 10 | 8.5 | 7 | 6 | 5 |
| int. | 11.5 | 12 | 12 | 13 | 12 | 12 | 12 | 10.5 | 8.5 | 7 | 6 | |
| Max. pressure drop (MPa) | cont. | 12.5 | 14 | 14 | 14 | 14 | 14 | 14 | 11 | 9 | 7 | 6 |
| int. | 16.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 14 | 10.5 | 9 | |
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 18 | 16 | 14 | 12 | |
| Max. flow (L/min) | cont. | 55 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | |
| Weight (kg) | 5.6 | 5.6 | 5.7 | 5.9 | 6 | 6.2 | 6.4 | 7 | 6.9 | 7.4 | 8 | |
3. Application
Hydraulic Drive Motor BMP , BMR For Mining , Forestry , Orchard Hydraulic Motor
♦ Orchard Sweeper.
♦ Garden pruning and shaping trees.
♦ Mining hydraulic transmission equipment.
♦ Hydraulic Wood Splitter
♦ Hydraulic Rotating
♦ Agricultural Forest Equipment
♦ Hydraulic system
♦ Hydraulic Components
