| Quantity: | |
|---|---|
119-1030-003
Xeriwell or Others
| Features: | Danfoss Char-Lynn Interchange | Item: | Disc Geroler Hydraulic Motor |
|---|---|---|---|
| Type: | Geroler Standard | Series: | 119-1030-003 |
| Manufactuerer: | Xeriwell | Origin: | China |
| Highlight: | 119-1030-003 Hydraulic Motor,Hydraulic Motor Interchange,Disc Geroler Hydraulic Motor | ||
Quick review:
| Model number | 119-1030-003 |
| DISPLACEMENT | 665.3 CM3/R |
| MOUNTING TYPE | STANDARD, 4 BOLT; 127.0 PILOT DIA. 16.76 DIA. HOLES ON 161.92 DIA. BOLT CIRCLE. |
| OUTPUT SHAFT | 57.15 DIA. STRAIGHT SHAFT WITH .500-20 UNF-2B THREAD IN END |
| PORTS | 1.3125-12 UN-2B SAE O-RING STAGGERED PORTS |
| FLOW OPTIONS | .5625-18 UNF-2B DRAIN SAE O-RING PORT |
| LOW PRESSURE RELIEF | NONE |
| PRESSURE / FLOW OPTION | NONE |
| GEROLER OPTION | STANDARD |
| SEAL OPTION | STANDARD |
| ACCESSORIES | NONE |
| SPECIAL FEATURE (HARDWARE) | NONE |
| SPECIAL FEATURE (ASSEMBLY) | NONE |
| PAINT / PACKAGING | NONE |
| CUSTOMER IDENTIFICATION | NONE |
| DESIGN CODE | THIRD |
Description:
The 10000 Series Char-Lynn motor replacement with same shape, same mounting, same performance
More Eaton Char-Lynn Hydraulic motor 10000 series replacement
| 119-1028-003 | M10210AA01AA01000000000000000C |
| 119-1029-003 | M10293AA01AA01000000000000000C |
| 119-1030-003 | M10406AA01AA01000000000000000C |
| 119-1031-003 | M10574AA01AA01000000000000000C |
| 119-1033-003 | M10293AA03AA01000000000000000C |
| 119-1034-003 | M10406AA03AA01000000000000000C |
| 119-1040-003 | M10210AA01AB01000000000000000C |
| 119-1042-003 | M10406AA01AB01000000000000000C |
| 119-1043-003 | M10574AA01AB01000000000000000C |
| 119-1046-003 | M10406AA03AB01000000000000000C |
| 119-1047-003 | M10574AA03AB01000000000000000C |
| 119-1089-003 | M10293AA03AA01000020000000000C |
