T6G T67G T6ZC series
Xeriwell or Others
The Parker Denison T6G, T67G, and T6ZC Series vane pumps are high-efficiency mobile hydraulic pumps specifically designed for power take-off (PTO) mounting in demanding applications. Their innovative design, featuring interchangeable cartridges and flexible mounting options, ensures optimal performance and adaptability for various systems, including tipping trucks, refuse vehicles, and cranes.
Key Features:
1) Optimized Circuit Design: Equipped with 'B' or 'C' cartridges, these pumps allow a clever combination of low flow at high pressure and high flow at lower pressure, optimizing hydraulic circuit efficiency.
B Size Cartridge: Flow rates from 5.8 to 50.0 ml/rev, with a maximum pressure of 300 bar.
C Size Cartridge: Flow rates from 10.8 to 100.0 ml/rev, with a maximum pressure of 275 bar.
2) High Efficiency: The pumps deliver mechanical and volumetric efficiency typically exceeding 94%, reducing heat generation and operational costs. They support speeds as low as 400 rpm at full pressure, enabling cold-start capability and smooth operation.
3) Wide Speed Range and Low Noise: With a speed range of 400 to 3600 rpm, these pumps ensure flexibility and reduced noise levels, making them suitable for environments where low noise is critical.
4) Flexible Mounting:
Single pumps offer 4 mounting positions.
Double pumps feature 32 mounting positions and a common large suction port for seamless integration into complex systems.
5) Compact and Serviceable Design: The replaceable cartridge assembly simplifies maintenance, minimizing downtime and contamination risk. The compact construction reduces installation space while maintaining robust performance.
The Parker Denison T6G, T67G, and T6ZC Series pumps deliver exceptional reliability, adaptability, and efficiency, making them the ideal choice for mobile hydraulic systems requiring high performance and versatile configurations.
