Charlynn orbital motor
Xeriwell or Others
Char-Lynn 2000 4000 6000 Series orbital motors are extremely reliable, compact, and have tremendous power density. They provide a way to meet many needs for cost-effective power transmission requirements. Multiple motors can be driven by a single power source (pump) and controlled using a wide array of valves and variable displacement pump controls. Motors can even be configured with electronic sensors to provide digital feedback for sensing both motor direction andoutput speed.
The Char-Lynn motor range consists of three major types based on the type of valving used to distribute fluid through the Orbit gear set (geroler or gerotor).
These three types are:
• Spool Valve
• Disc Valve
• VIS (Valve-in-Star)
Migration from one valve technology to the next enhances motor performance in terms of efficiency, pressure rating, displacements, and motor output torque capability.
Char-Lynn 2K 4K 6K 10K Orbital Hydraulic motor
Motor options include:
• Displacement size (cubic inches or cc’s per revolution)
• Output shaft size and type
• Mounting flange type
• Porting interface
• A wide selection of special features such as integrated brakes, sensors, integrated crossover relief valves, 2-speed capability, manifold valve packages, and environmental protection suited for corrosive environments.
Type: Charlynn 2K, 4K, 6K, 10K
