Product Description

Features:	Same Than OMM Motors	Product Name:	Small Hydraulic Motors BMM32
Brand Name:	Xeriwell	Model Number:	BMM / MM / EATON J Series OMM Motor
Displacement:	8cc,12cc,20cc,32cc,40cc,50cc	Application:	Brush Cutters Mower Forestry Equipment
Highlight:	mini hydraulic motor , compact hydraulic motor

Small Hydraulic Motors BMM32 / OMM32 For Marine , Engineering Hydraulic Equipment

► Characteristic Features

1. BMM Hydraulic Motor series of motor, with its shell made of ductile cast iron of adequate intensity, can be applied to sitations with less load and interval operation, widely to agriculture, forestry, plastics, machine tools and mine machines, etc.

2. This series of motor can replace OMM, MM series.

3. With the axial oil distribution structure, it is smaller, high efficiency and long life.

4. Shaft seal can bear high

pressure of motor of which can be used in parallel or in series.

► Specification

Xeriwell	BMM
M+S	MM
EATON	J Series
	OMM

Type		BMM8	BMM12	BMM20	BMM32	BMM40	BMM50
displacement		8.2	12.9	19.9	31.6	39.8	50.3
Max speed(rpm)	rated	1537	1256	814	513	452	358
	Cont.	1950	1550	1000	630	500	400
	int.	2450	1940	1250	800	630	500
Max Torque (N*M)	rated	8	13	19	31	37	33
	Cont.	11	16	25	40	45	46
	int.	15	23	35	57	70	88
	peak	21	33	51	64	82	100
Max speed (kw)	rated	1.3	1.7	1.7	1.7	1.7	1.2
	Cont.	1.8	2.4	2.4	2.4	2.2	1.8
	int.	2.6	3.2	3.2	3.2	3.2	3.2
Max pressure drop(MPa)	rated	9	9	9	9	8.5	6
	Cont.	10	10	10	10	9	7
	int.	14	14	14	14	14	14
	peak	20	20	20	16	16	16
Max flow(L/min)	rated	14	18	18	18	20	20
	Cont.	18	20	20	20	20	20
	int.	20	25	25	25	25	25
Weight(kg)		1.9	2	2.1	2.2	2.3	2.4
