| Quantity: | |
|---|---|
BMM
Xeriwell or Others
| Type: | Gerotor Hydraulic Motor | Brand: | Xeriwell |
|---|---|---|---|
| Model No.: | BMM32 | Power: | Hydraulic Oil |
| Displacement: | 8,12, 20, 32, 40, 50 ML/R | Weight: | 2.5 Kgs |
| Feature: | Replace OMM, M+S MM, EATON J Series | Application: | Plastic, Agricultural, Forestry, Industrial, Etc. |
| Highlight: | lightweight hydraulic motor,omr hydraulic motor | ||
16mm Cylindrical Shaft BMM Gerotor Hydraulic Motor Buttom Ports
China top quality BMM motor provided by Xeriwell Technology.
Apply to lower torque powertransmission systems like rolling, winching, convoying, etc.
Characteristic features:
• Smooth running over the entire speed range
• Constant operating torque over a wide speed range
• High starting torque
• High return pressure without the use of drain line (High pressure shaft seal)
• High efficiency
• Long life under extreme operating conditions
16mm Cylindrical Shaft
Geometric displacement 32 cm³
• Max. speed continuous. 630 min-1
• Max. speed intermittent.⊃1; 800 rpm
• Max. torque continuous. 40 Nm
• Max. torque intermittent.⊃1; 57 Nm
• Max. output continuous. 2.4 kW
• Max. output intermittent.⊃1; 3.2 kW
• Max. pressure continuous. 100 bar
• Max. pressure intermittent.⊃1; 140 bar
• Max. pressure peak⊃2; 160 bar
Model Crossing:
| MOTOR CROSS REFERENCE TABLE | ||||||||
| Xeriwell HYDRAULIC | M+S HYDRAULIC | EATON CHAR LYNN | ROSS TRW | WHITE CROSS | PARKER | SAM BREVINI | BOSCH RECROTH | |
| BMM | MM MLHK | J SERIES | OMM | BGM | MGX | |||
Main Specifications:
| Type | BMM8 | BMM12 | BMM20 | BMM32 | BMM40 | BMM50 | |
| displacement | 8.2 | 12.9 | 19.9 | 31.6 | 39.8 | 50.3 | |
| Max speed(rpm) | rated | 1537 | 1256 | 814 | 513 | 452 | 358 |
| Cont. | 1950 | 1550 | 1000 | 630 | 500 | 400 | |
| int. | 2450 | 1940 | 1250 | 800 | 630 | 500 | |
| Max Torque (N*M) | rated | 8 | 13 | 19 | 31 | 37 | 33 |
| Cont. | 11 | 16 | 25 | 40 | 45 | 46 | |
| int. | 15 | 23 | 35 | 57 | 70 | 88 | |
| peak | 21 | 33 | 51 | 64 | 82 | 100 | |
| Max speed (kw) | rated | 1.3 | 1.7 | 1.7 | 1.7 | 1.7 | 1.2 |
| Cont. | 1.8 | 2.4 | 2.4 | 2.4 | 2.2 | 1.8 | |
| int. | 2.6 | 3.2 | 3.2 | 3.2 | 3.2 | 3.2 | |
| Max pressure drop(MPa) | rated | 9 | 9 | 9 | 9 | 8.5 | 6 |
| Cont. | 10 | 10 | 10 | 10 | 9 | 7 | |
| int. | 14 | 14 | 14 | 14 | 14 | 14 | |
| peak | 20 | 20 | 20 | 16 | 16 | 16 | |
| Max flow(L/min) | rated | 14 | 18 | 18 | 18 | 20 | 20 |
| Cont. | 18 | 20 | 20 | 20 | 20 | 20 | |
| int. | 20 | 25 | 25 | 25 | 25 | 25 | |
| Weight(kg) | 1.9 | 2 | 2.1 | 2.2 | 2.3 | 2.4 | |
Model: BMM32
Shipping Weight: 2.3 kg
Manufactured by: Xeriwell Technology
Please do not hesitate to contact us for further information, inquiries or orders.
Thank you for choosing 'Xeriwell' Hydraulics.
